4102Continuity Tester
Descriptions:
This product is designed to measure the continuity of electric circuits and components. The measurement result will be indicated by LED and buzzer. The illumination is very helpful when technician is working in dark environment.
Specifications:
| CONTINUITY TEST | |
|---|---|
| RESISTANCE | 0-100KΩ |
| NO-LOAD VOLTAGE | < 7V |
| CURRENT | < 70μA |
| MAXIMUM VOLTAGE | ≦ 400V AC |
| FREQUENCY | 0-60Hz |
| POWER SUPPLY | |
| BATTERY | AAA x 3 |
| REFERENCE CONDITION | |
| WORKING TEMPERATURE | 0-50°C (32-122°F) |
| STORAGE TEMPERATURE | -20-60°C (-4-142°F) |
