- 12-690V Voltage Tester with LED Display
733712-690V Voltage Tester with LED Display
Descriptions:
LED voltage tester is a professional 2-pole voltage tester, which provides electricians with a versatile high quality Voltage and Continuity tester. Suitable for checking AC/DC 12-690V.
Measurement by LED Display
Features Function:
1. Double-pole Test
2. High Voltage Indication
3. Phase Rotation Test
4. Polarity Indication
5. Continuity Test
6. Illumination
Features:
- With Bauart, ETL, CE and UKCA Approval.
- Protection class: IP 64
- Self-Diagnostic Test.
- Auto-power ON/OFF.
- Probe cover protects user and probe tip.
- Compact design, light weight and portable.
- Phase rotation test with R/L LEDs displayed.
- Two-way clip for adjustable spacing of probes.
- AC and DC voltage test by seven stages LED displays.
Specifications:
| VOLTAGE MEASUREMENT | |
|---|---|
| VOLTAGE RANGE | 12-690V AC/DC |
| LED RESOLUTION | Europe:±12/24/50/120/230/400/690V America:±12/48/120/208/240/277/480/600V |
| TOLERANCE (THRESHOLD VOLTAGE) |
Light on at more than : 7±5V (12V LED) : 18±5V (24V LED) : 37.5±5V (50V LED) : 75%±5% of nominal voltage (120/230/400/690V LED) |
| RESPONSE TIME | < 0.5s |
| HIGH VOLTAGE INDICATION | |
| VOLTAGE RANGE | 50V-690V AC |
| PHASE ROTATION TEST | |
| SYSTEM | Three-phase system AC 50/60Hz |
| PHASE ANGLE | 120±5 DEGREE |
| CONTINUITY | |
| DETECTION RANGE | 0-550KΩ |
| TEST CURRENT | Approx. 1.5μA (battery 3V, 0Ω) |
| INTERNAL BATTERY CONSUMPTION | Approx. 30mA (battery 3V,0Ω) |
| OPERATING ENVIRONMENT | |
| BATTERY | 3V (AAA 1.5V *2) |
| TEMPERATURE | -10-55°C operation -20-60°C storage No condensation |
| HUMIDITY | MAX 85% RH |
| SAFETY | |
| STANDARD CATEGORY | Bauart: EN 61243-3 / IEC 61243-3 EN 61010-1 / IEC 61010-1 CAT III 690V / CAT IV 600V ETL: UL 61010-1 CAT II 600V / CAT IV 600V |
| IP CODE | IP64 |
| POLLUTION LEVEL | 2 |
