7128C600A Digital Clamp Meter w/Temperature Measurement
Descriptions:
This is a low power consumption, high accuracy and stable hand-held 6000 counts true-rms clamp meter.It performs measurements of DC voltage/current, AC voltage/current (TRMS), resistance, diode, continuity, temperature, capacitance, frequency, duty cycle, and non-contact voltage sensing. The meter has auto-sleeping function with 15 minutes inactivity.
Features:
- With CE Approval
- AC/DC Voltage Measurement
- AC Current Measurement
- Resistance Measurement
- Diode Measurement
- Continuity Measurement
- Non-contact Voltage Sensing
- Frequency (Hz/duty cycle) Measurement
- Capacitance Measurement
- Temperature Measurement
- Back-light and illumination
- AAA battery x 4
Specifications:
GENERAL SPECIFICATION |
||
---|---|---|
Display |
LCD |
|
Maximum Resolution |
6000 3-6/7 digits |
|
Range |
Auto / Manual |
|
DC Voltage Range |
0~600V DC |
|
AC Voltage Range |
0~600V AC |
|
AC/DC Current Range |
0~600A |
|
Resistance Range |
0~60MΩ |
|
Frequency Range |
0~9.999kHz |
|
Temperature Range |
-55°C~1300°C(-67°F~2372°F) |
|
DC Voltage:0~600VDC |
||
Range |
Resolution |
Accuracy |
600.0 mV | 0.1 mV | ±1%±2 digits |
6.000V | 0.001V | |
60.00V | 0.01V | |
600.0V | 0.1V | |
AC Voltage:0~600VAC |
||
Range |
Resolution |
Accuracy |
6.000V | 0.001V | ±1%±2 digits |
60.00V | 0.01V | |
600.0V | 0.1V | |
AC/DC Current:0~600A |
||
Range |
Resolution |
Accuracy |
60.00A | 0.01A | ±2.5%±8 digits |
600.0A | 0.1A | ±2.5%±5 digits |
Resistance:0~60MΩ |
||
Range |
Resolution |
Accuracy |
600.0Ω | 0.1Ω | ±1%±3 digits |
6.000kΩ | 0.001kΩ | |
60.00kΩ | 0.01kΩ | ±1%±1 digits |
600.0kΩ | 0.1kΩ | |
6.000MΩ | 0.001MΩ | |
60.00MΩ | 0.01MΩ | ±2%±3 digits |
Diode and Continuity |
||
Diode Forward Voltage 0~3.3V | Continuity buzzing when resistance is < 50Ω | |
Temperature(depending on K-type thermocouple range) |
||
Range |
Resolution |
Accuracy |
-55°C ~400°C (-67°F ~752°F) | 1°C / °F | ±2%±3digits |
400°C ~1300°C (752°F ~2372°F) | 1°C / °F | |
Capacitor:0~60.00mF |
||
Range |
Resolution |
Accuracy |
6.000nF | 0.001nF | ±3%±10digits |
60.00nF | 0.01nF | |
600.0nF | 0.1nF | |
6.000uF | 0.001uF | |
60.00uF | 0.01uF | |
600.0uF | 0.1uF | |
6.000mF | 0.001mF | |
60.00mF | 0.01mF | |
Frequency:0~9.999kHz |
||
Range |
Resolution |
Accuracy |
9.999Hz | 0.001Hz | ±1%±2digits |
99.99Hz | 0.01Hz | |
999.9Hz | 0.1Hz | |
9.999kHz | 0.001kHz | |
Duty Cycle |
||
Range |
Resolution |
Accuracy |
0~100% | 0.1% | ±1%±5digits |
